Every Second, Accounted For.Every Second, Accounted For.

1. 01

   6.0–6.4×

   Original 50-step ÷ PAI 8

   Schedule Beats Precision

   PAI 8 (an 8-step schedule) is 6.0–6.4× faster than the original 50 steps. At the same schedule, INT8 is only 3.6–10.2% faster than FP8 (denoise compute; single cold runs with one seed, so treat small gaps as indicative).

   See the Data
2. 02

   600.5 → 297.2 s

   One segment, end to end

   References Are the Cost — 448 Halves It

   In a character-swap run the reference video is 47% of the DiT sequence. Preprocessing it at a 448-pixel short edge (instead of 768) cut one segment from 600.5 s to 297.2 s.

   See the Data
3. 03

   15.91 / 15.92 GiB

   Whole-card NVML peak

   16 GB Fits, Barely

   With references the DiT reserves up to 13.6 GiB and the whole card peaks at 15.91 of 15.92 GiB. Headroom of 1.6 GiB held; 0.8 GiB did not.

   See the Data
4. 04

   3.4×

   Reference video encode, RTX 5080 vs. RTX 3060

   Put Each Encoder Where It Fits

   The full-precision Qwen3-VL text encoder (te-gb10) stays on the DGX Spark: about 52 GB resident, up to 60 GB during a call — far more than a 16 GB card can spare next to the DiT. Reference video encoding moved from the RTX 3060 to the RTX 5080: 72–74 s instead of 248–250 s.

   See the Data
5. 05

   4 / 4

   Seeds that leaked

   Turbo 4 Is Fast, but It Leaks

   In character-swap runs (768 reference video, two characters), Turbo 4’s DiT takes 229–236 s versus 466–473 s for PAI 8 — yet the source character’s costume leaked into the output on 4 of 4 seeds. Production ref2va stays on PAI 8.

   See the Data
6. 06

   16

   Runs that failed or were canceled

   What Failed, and Why

   Three NF4 DiTs failed to load, Turbo 4 was rejected when the pipeline forced 8 steps, three characters at 768 ran out of GPU memory, and the BF16 phase image DiT was refused before it started (not enough free VRAM). All of it is in the table.

   See the Data

Times in seconds, VRAM in GiB (2^30 bytes). Steps that run at the same time (video and audio decode, reference video and audio encode) overlap, so the steps add up to more than the total.

Measured 2026-10-18Single run eachWeb copy is loudness-normalized; the raw output is about −37 to −50 LUFS, AAC 32 kHz.

AI-generated · Qwen-Image 2.1

Qwen-Image 2.1 Stills

AI-generated · Qwen-Image 2.1

1152×672, 40 steps. Text encode, DiT and VAE run on the RTX 5080; compositing on the CPU. These stills were also the first frames for fl2va.

• Cliff at Dawn26.0 srun 3a6d932d
• Neon Rain26.9 srun 0e2463b8
• Aurora Sea25.9 srun d47c0fa1
• Close-Up25.8 srun 577fc7a4

No video in this section: the swap experiments used a third-party reference clip, so nothing derived from it is published. The numbers are.

DiT stage (wall)

From the start to the end of the DiT stage (all denoising steps), including AdaLN prep, input assembly and release. This page uses it by default.

Denoise compute

The recorder’s h3.denoise_av.compute_ms: the denoising loop only. Older reports quote it, so it appears as a secondary column.

End to end

Wall time from run creation to completion. Listed only when every step ran in that run; rows that reuse steps from another run say “Not end to end.”

Device

Each step’s device comes from the run record’s node and resource group. If the archive lacks it, the step says “Placement not recorded” — never a guess.

GiB and GB

RTX 5080 and RTX 3060 memory is always GiB (2^30 bytes). All DGX Spark memory figures (meminfo and its torch peaks) use GB (10^9 bytes) and are labeled.

torch and NVML

Allocated / reserved are the DiT process’s PyTorch peaks. Whole-card NVML is sampled at 2 Hz, includes other processes’ CUDA contexts, and is a lower bound.

1. 01DiT Benchmark: 40 H3 DiT VariantsWhich DiT variant is fastest and lightest on VRAM, and do quantization, acceleration and AdaLN settings change the output?2026-10-17

   With the same text conditioning, reference latents and seed (42), only the DiT component changed: FP8/INT8/BF16/NF4 × original 50-step/PAI 8/Turbo 8/Turbo 4, plus attention and AdaLN settings, text only (t2va) and with two character images (ref2va), at 768×448 and 124 frames. Every DiT that loaded ran on the RTX 5080 with layer streaming. 40 DiT variants benchmarked; 37 produced video; 3 NF4 variants failed to load. Text encoding ran once on te-gb10 on the DGX Spark and was shared.

   Findings

   • Speed is set by the schedule first and quantization second: at the same schedule INT8 is 3.6–10.2% faster than FP8, BF16 is 1.6–2.0× slower, and the original 50 steps are 6.0–6.4× slower than PAI 8 (denoise compute).
   • Fastest text-only: INT8 PAI 8 (DiT 33.2 s, denoise 26.0 s); dit-5080 in production (FP8 PAI 8) takes 37.8 s / 28.9 s. Fastest with references: INT8 Turbo 4 (83.9 s / 74.4 s); production FP8 PAI 8 takes 120.9 s / 115.5 s.
   • Exp. 01 measured each variant’s first call after a cold load, on 2026-10-17. The production runs on 2026-10-18 are fl2va calls on an already loaded DiT: 31.7–38.7 s (31.7–33.2 s once warm), versus 37.8 s for the same dit-5080 here. Compare rows within one experiment, not across experiments.
   • AdaLN mode and release after use (host/drop) do not change the output — decoded MD5s match — but online AdaLN adds 23–32 s per call outside the steps (fixed 2–8 s, off 2–3 s).
   • With references, PAI 8 and Turbo 8 paste the black-background reference into the clip (21–22 and 37–43 of 124 frames); Turbo 4 and the original schedule show none. All three NF4 variants failed to load: the quantized weights lack comfy_quant metadata and the pinned loader rejects them.

   Caveats

   • One prompt and one seed per scenario; only the first call after loading was measured, and load times depend on the page cache.
   • Text and reference encodes ran once and were reused, so each row’s run time covers DiT + decode + mux only, not end to end.
   • The two reference images were transparent PNGs whose transparent areas turn black at input, which makes the pasting very visible.

   40 rows in the speed table →
2. 02Character Swap Runs R1–R6Can two character images replace the two characters in a reference clip, which prompt works, and how long does it take?2026-10-18

   ref2va-pc: text encode on te-gb10 on the DGX Spark, reference video encode on the RTX 5080 (the R3/R6 series on the RTX 3060), reference audio encode and audio decode on the RTX 3060, DiT and video decode on the RTX 5080. The runs compared prompt wording, transparent versus white-background images, and PAI 8 versus Turbo 4 (seed 42, 768×448, 124 frames).

   Findings

   • Prompt v1 (reference video fully_preserved) copied the original characters’ looks (R1, R2); v2 treated the video as a weak_reference for camera and motion only and spelled out the costume change, which replaced both characters (R5).
   • PAI 8 with two images and a 5.17-second clip: DiT 456.6–480.6 s, full run 581.8–607.4 s. The DiT sequence is 79,296–80,832 rows, about 2.3× the images-only case (35,136).
   • Reference video encode took about 71.9–73.7 s on venc-5080 and 247.6–250.2 s on venc-3060, so production moved it to the RTX 5080.
   • Turbo 4 failed: R3 and R6 were rejected by the LoRA sampling contract because the pipeline pinned 8 steps (INVALID_ARGUMENT); R3b ran out of GPU memory in the DiT (needed 1.08 GiB more, 1.07 GiB free); R6b was canceled mid-run.

   Caveats

   • Single seed; swap quality was judged by eye.
   • The R3 series encoded the reference video on the RTX 3060, so those venc times are not comparable with R1, R2 and R5.
   • te-gb10 still held two copies of the text encoder in these runs (fixed in experiment 11), so its memory figures are inflated.

   7 rows in the speed table →
3. 03VAE: Resident vs. On DemandShould the video VAE processes on the RTX 5080 stay loaded, or start only when needed?2026-10-18

   vae-5080 (video decode) and venc-5080 (reference video encode) keep their weights in pinned host memory and copy them to the GPU on each call. Three setups — both resident, only venc stopped, both stopped — were compared on cold starts, first versus warm calls, DiT speed and free memory.

   Findings

   • Loading on demand adds about 24–27 s per render (an estimate: cold starts are 11.9–15.8 s for vae-5080 and 8.6–10.7 s for venc-5080, and a first call adds 1.1–1.8 s to decode and 0.8 s to encode).
   • DiT speed did not change (denoise 463.2 s versus 463.8–464.3 s resident) and the latents were bit-identical; the only gain was host memory free during the DiT, 19.1 → 34.3 GiB, so the VAEs stay resident.
   • Turbo 4 (online AdaLN) with a reference video fit only with both VAEs stopped: DiT 252.8 s with about 0.3 GiB of the card left; with only venc stopped it ran out of GPU memory.

   Caveats

   • The 24–27 s figure adds up separate cold-start and first-call measurements; it is not one end-to-end run.
   • “Resident” means the process and its CUDA context (about 0.9 GiB each) stay on the 5080; the weights still move to the GPU on every call.
4. 04Turbo 4 with Fixed AdaLNWith a precomputed AdaLN, does Turbo 4 fit on the RTX 5080 next to both resident VAEs, and does the output change?2026-10-18

   A 465 MB precomputed AdaLN sidecar was built for Turbo 4 (INT8, lx4 LoRA) so it no longer computes AdaLN online. Under the R2 and R5 conditions the runs measured VRAM and DiT time and compared the latents value by value with the online version.

   Findings

   • It fits with both VAEs resident: DiT 229.3–235.3 s (PAI 8 takes about 470 s); torch allocated/reserved 11,644/13,070 MiB (PAI 8: 11,418/12,842), real headroom 1.40 versus 1.61 GiB.
   • The latents are identical to the online version (1,193,472 video values and 13,248 audio values, max difference 0).
   • Quality: seed 42 already leaks the original character’s white frilled skirt (experiment 08 confirms it on 4 of 4 seeds), so ref2va-pc stays on PAI 8.

   Caveats

   • Text and reference encodes were reused from R2/R5, so these times cover the DiT (plus decoding under R5) only.

   2 rows in the speed table →
5. 05Swap Limits with a 768 Reference VideoWith a 768 reference video, how many frames and characters per segment fit on the RTX 5080?2026-10-18

   The full ref2va-pc route ran in the production setup with both VAEs resident (seed 42), testing three characters at 124 frames and two at 141 frames for PAI 8 and Turbo 4 fixed. The third character image duplicates the second, so it tests memory and time only.

   Findings

   • PAI 8: two characters at 124 frames works (headroom 1.61 GiB); three at 124 frames ran out of GPU memory (the FFN needed 2.49 GiB with 2.24 GiB free), and so did two at 141 frames (needed 2.34 GiB contiguous; 1.55 GiB free plus 1.71 GiB fragmented).
   • Turbo 4 fixed: three characters at 124 frames ran out of memory; two at 141 frames succeeded (DiT 269.9 s, headroom 0.695 GiB) — but see experiment 08 for its quality problem.
   • All three failures hit at the very start of the DiT (0 steps done), yet text and reference encodes run first, so each failed run still took 118.0–133.5 s.

   Caveats

   • The third character is a duplicate image: it speaks to memory and time, not real three-character quality.
   • The out-of-memory boundary depends on fragmentation, so other inputs may land differently.

   4 rows in the speed table →
6. 06Reference Video at 448What happens to speed, VRAM and quality when the reference video is preprocessed at 448 instead of 768?2026-10-18

   Under R5’s conditions (PAI 8, two characters, 124 frames, seed 42), only the reference video’s preprocessing short edge changed from 768 to 448 (1280×720 → 800×448); the output stays 768×448. The runs also confirmed that a 768 control matches R5 bit for bit and that the Studio UI and MCP produce identical results.

   Findings

   • One segment went from 600.5 to 297.2 s; DiT 470.7 → 223.9 s (57.9 → 27.5 s per denoising step, p50); reference video encode 73.7 → 28.6 s; DiT sequence 80,832 → 52,544.
   • DiT torch allocated/reserved dropped from 11.15/12.54 GiB to 8.24/10.40 GiB.
   • Quality (one seed): characters and costumes hold and the cut lands at the same point; motion is calmer (median frame-to-frame change 3.02 versus 4.02, source 6.22) and mouth movement is smaller.
   • The 768 control’s latents and decoded video match R5 bit for bit, and the 448 results from the Studio UI and from MCP are bit-identical.

   Caveats

   • Quality was checked on one seed only; whether 448 leaks costumes on other seeds is untested.
   • R5’s text encode was a warm call while the 768 control hit the first call after a restart (79.9 s), so totals are compared against R5.

   3 rows in the speed table →
7. 07Swap Limits at 448With a 448 reference video, how long can a segment be and how many characters fit?2026-10-18

   With a 448 reference video, PAI 8 and seed 42 in the production setup, the runs tested two characters at 124, 141 and 158 frames and three at 124 frames, then fitted a VRAM model to the five successful points. The third character image is a duplicate.

   Findings

   • Everything succeeded: two characters at 124/141/158 frames (DiT 223.9/257.4/282.3 s, totals 297.2/339.6/365.7 s) and three at 124 frames (322.5/411.2 s), with headroom of 4.52/4.16/3.76/3.20 GiB.
   • VRAM model: allocated peak ≈ 2,892 MiB + 0.1056 MiB × sequence length (residuals under 35 MiB across five points); 1.6 GiB of headroom has proven safe, 0.8 GiB has not.
   • The limits are wired into One-Click Character Swap: up to 158 frames per segment for one or two characters and 124 for three. The 141-frame output copied the source’s subtitle-removal blur into shot 1.

   Caveats

   • The third character is a duplicate; lengths of 175 frames and up are model predictions, not measurements, so this page does not plot them.

   3 rows in the speed table →
8. 08Turbo 4 Across Four SeedsDoes Turbo 4 leak the original character’s costume every time?2026-10-18

   Under R5’s conditions (768 reference video, two characters, 124 frames), seeds 42, 7, 1234 and 31337 compared PAI 8 with Turbo 4 fixed. Seed 42 is a full pipeline run; the other seeds reuse R5’s conditioning and rerun only the DiT and decoding.

   Findings

   • Turbo 4 leaked the original white frilled skirt on 4 of 4 seeds and copied the subtitle-removal blur on 4 of 4; PAI 8 leaks too (1 clear, 2 faint, 1 clean) but copied the blur on 0 of 4.
   • Speed: PAI 8 DiT 465.8–472.6 s, Turbo 4 229.2–235.5 s.
   • Decision: ref2va-pc stays on PAI 8 with no Turbo 4 draft route; for speed, use PAI 8 with a 448 reference video (DiT 224 s).

   Caveats

   • Four seeds are not a failure rate; leak severity is a visual grade (none / faint / clear).

   6 rows in the speed table →
9. 09Checking an External Reference-Cost AnalysisAn outside analysis blamed reference media for slow ref2va runs. Is it right, and where does the cost really go?2026-10-18

   The external analysis was checked claim by claim against the code, run records and payloads: R1’s DiT sequence was broken down, eight runs were used to fit step time against sequence length, and the baseline runs E1–E4 from 2026-10-17 are listed.

   Findings

   • Broadly right, but R1’s main cost is the reference video, not the images: of 79,268 rows, reference video 37,296 (47%), Qwen vision 16,944 (21%), reference images 10,880 (14%), target video 12,432 (16%), text and audio 1,716.
   • Step-time model: step(L) ≈ 1.68e-4·L + 6.81e-9·L² seconds, within about ±3% from 13k to 81k rows (RTX 5080, FP8 PAI 8).
   • Errors in the report: video decoding is actually FP32, and aenc’s 6.98 s was mostly waiting on the same file download. A two-step text encode, cost records and the reference_video_short_edge parameter (experiment 06) are now implemented.

   Caveats

   • The time model applies only to the RTX 5080, FP8 PAI 8 and a 768×448×124 target; “reusing the conditioning when only the seed changes saves about 100 s” is an estimate, not yet implemented or measured.

   5 rows in the speed table →
10. 10Front End and MCP Field TestWhat breaks when a full experiment is run by hand through the UI and through MCP?2026-10-18

    Experiment 06’s 448 run was prepared and executed through the installed MCP and through the Studio UI, logging every problem found and comparing the two paths’ outputs.

    Findings

    • Phase 1 found 26 issues, 3 of them major (MCP dropped large outputs, run inputs were not visible, the inference page ordered materials differently from Studio); all are fixed.
    • Phase 2 found 7 new items, including latent hashes that include load metadata, cold calls of the audio component that are not numerically reproducible, and a first text encode about 50 s slower after a restart; 2 are fixed.
    • The 448 results from the UI and from MCP are bit-identical.

    Caveats

    • The screenshots show the pre-rename UI, so they are not published; the site’s walkthrough videos are recorded separately in the English UI.
11. 11Reverse Prompt Memory on DGX SparkCan image reverse prompting run on the DGX Spark next to the resident text encoder te-gb10?2026-10-18

    Image reverse prompting (qimg-vision-gb10, Qwen3-VL-4B BF16) moved to the DGX Spark next to te-gb10. After fixing the deployment, the runs measured memory, load and call times, and fixed te-gb10 loading a duplicate text encoder after a ref2va call.

    Findings

    • Before the fix, te-gb10 loaded a second, identical text encoder after a ref2va call, using 51.5 GB more. With sharing there is one copy: the ref2va call peaks at 56.81/59.66 GB allocated/reserved and settles at 51.69/52.30 GB, and the output matches R5 bit for bit.
    • The GB10 uses unified memory, so available capacity is MemAvailable − 4 GiB (64.10 GB), not torch’s mem_get_info, which reports only 8.53 GB because it ignores reclaimable page cache.
    • The 4B reverse-prompt model loads in 62.5 s, captions in 5.3 s and analyzes in 85.8 s; next to te-gb10, MemAvailable bottomed at 57.29 GB, and keeping it resident costs about 11.6 GB.

    Caveats

    • DGX memory figures are in GB (10^9 bytes); te-gb10’s ref2va peak with both models resident is only estimated, not measured.
    • The caption contained errors (it called horizontal throwing lines vertical stripes); quality was checked on a single image.

    2 rows in the speed table →
12. 12Image Generation Check (Qwen-Image 2.1)Does Qwen-Image 2.1 on the RTX 5080 match the author’s earlier image tool, DiT Studio, and does it fit while the video components stay resident?2026-10-18

    The first GPU validation ran 30 runs (28 via the API, 2 via Image Studio). It compared eight historical cases pixel for pixel and measured time and VRAM for three DiT components (BF16 phase, BF16 stream and Qwen-Image GGUF Q4_K_M), full versus tiled VAE decoding, and the cost of intermediate previews. Every GPU step ran on the RTX 5080; compositing on the CPU.

    Findings

    • All eight cases match DiT Studio’s output pixel for pixel in RGBA (max difference 0); BF16 phase and stream latents are bit-identical, and batch and UI images match single runs.
    • At the time only the GGUF route finished in the production state: BF16 phase was refused at admission (needed 14.77 GiB, 11.66 GiB available), and BF16 stream finished its DiT (32.5–33.2 s at 1024²) but then ran out of memory in VAE decoding, because the text encoder and DiT did not release the CUDA cache after their calls.
    • VAE decoding at 1024² full takes 0.74–0.79 s (7.05 GiB allocated); tiled decoding shows thin pink vertical lines; 1536² full is not feasible on a 16 GB card.
    • Intermediate previews (every 4 steps) delivered 11 of 11 images with GPU time per step unchanged (713.8 versus 712.7 ms) and 1.26 GiB more host memory.

    Caveats

    • The GGUF route uses fine-tuned Q4_K_M weights, not the original weights; image reverse prompting was out of scope.
    • Per-run numbers come from the archived comparison page (the raw run records are not in the archive).

    17 rows in the speed table →
13. 13Image DiT Fix VerifiedAfter releasing the CUDA cache after each call, does BF16 stream complete in the production state?2026-10-18

    After the fix (release the CUDA cache after every call and clear frames first on failure), the t2i-pc run that failed in experiment 12 was repeated in the RTX 5080 production state (H3’s vae-5080 and venc-5080 resident): same prompt (a ceramic cup), 1024², 40 steps, seed 42, full VAE decode, with previews off and with a preview every 4 steps.

    Findings

    • Pass: 47.9 s end to end (text encode 12.15 s, DiT 33.04 s, VAE 1.82 s), whole-card NVML peak 11,849 MiB, and the image matches the pre-fix reference pixel for pixel.
    • With a preview every 4 steps, all 11 were published, GPU time per step (p50) rose only 9.0 ms (+1.1%), and the run took 43.0 s end to end (text-encode process already warm).
    • Applied: t2i-pc and i2i-pc now use the BF16 stream DiT with the preview VAE enabled.

    Caveats

    • i2i, four-image batches and 1536² have not been rechecked on the GPU since the fix; the grid texture in preview thumbnails comes from the preview method itself.

    2 rows in the speed table →
